Specifications
System | 4 cores, 2.0GHz 2G RAM, supports up to 8G 16G ROM, supports up to 256G Android 11.0 Linux 5.10 |
Display | 12.1″ capacitive touch display, supports 5-finger touch Resolution:1280*800px Brightness:750cd/mi Anti-dazzle display under strong light |
Communication | 4G/5G WiFi 2.4G/5G BT 4.2 GNSS (optional meter-level/sub-meter/centimeter-level positioning board) Card) SocketCAN*4 Maximum support RS232*2/R5232*1 & RS485*1Debug RS232 (for debugging only) ADCIN voltage detection*2, maximum input voltage 12V ADC IN current detection*2, 4~20mA DC OUTPUT 12V output*4 IO INPUT input*4 USB 2.0*1 Gigabit Ethernet*1 CP ISOBUS VT |
Audiovisual and Sensing | Supports up to AHD camera 1080P*6 or 720*8 or 7202441080*4 Support CP AVM 360° surround image Microphone*1 Internal speaker*1 or external speaker*2 or external two-channel sound source output G-Sensor*1 |
Environmental parameters | Protection level: IP67 Vibration:MIL-STD-810 Road vehicle standards: ISO16750 Working temperature: -30’C-+70℃ Humidity:0%-90%RH Storage humidity:-40°℃-+85’℃ Salt Show: The whole machine is sprayed with salt spray for 48 hours |
Power management | Power supply 5-36V DC input Start ignition ACC status detection Power supply voltage detection Overcurrent, overvoltage and undervoltage, anti-reverse connection protection |
Function button indicator light | Power switch key*1, custom function button*1 | Connector | 26PIN connector*2 M12 X-code aviation plug*1 SMA connector*1 TNC connector*2 USB 2.0 interface*1 |
Custom functions | Supports 1 street light target, 16 LEDs (optional) | Specification | Dimensions (W*H*D): 317.8*219.6*34.5mm Weight: 1.73kg |
